New stock from Roco
Electric locomotive 241 007 of the Hector Rail.
■ Name of locomotive: "Bond"
■ Many separately applied plug-in parts partially etched
■ Used in the goods traffic in Denmark, Germany, Sweden and Norway
■ In digital mode, with switchable high beam and individually switchable head or taillight
The locomotive class 241, known in Germany as class 185, which belongs to Bombardier's TRAXX series, operates for the private Swedish railway company Hector Rail. Hector Rail uses the two-system locomotives built from 2007 onwards in Sweden, Norway, Denmark and Germany. In 2011 two more locomotives were delivered, so twelve locomotives (241.001-012) are still operating. The locomotives with the wheel arrangement 'Bo'Bo' reach a maximum speed of 140 kilometers per hour. A special feature of all Hector Rail locomotives is their unique proper name.
General data
Coupling
NEM shaft 362 with close coupling mechanism
Minimum radius
358 mm
Flywheel
yes
Number of driven axles
3
Number of axles with traction tyres
2
Scale
H0
Epoch
VI
Article number
79948
Electrical
Motor
5-pole motor
Head light
3 headlight, dependent on the direction of travel/2 tail lights, dependent on the direction of travel
LED head light
yes
Additional light function
yes
Control
AC
Interface
Electrical interface for traction units PluX22
Digital decoder
PluX22
Decoder-Type
MX645P22
Sound
yes
Buffer capacitor
yes
Measurements
Length over buffer
217 mm
